Upping Your Maritime Game: The 3-Function Pressure Vacuum Valve
Triple-Duty Pressure Vacuum Control Valve in Action
Level up your ship's ballast water treatment systems with the revolutionary 3-Function Pressure Vacuum Valve. This advanced valve adds an nitrogen gas preservation feature to the traditional air vent head, improving efficiency and environmental compliance.
This bad boy opens when the pressure hits 200-300 mmWC and takes over in a vacuum range of 200-300 mmWC. It's an essential addition for vessels striving for performance and eco-friendliness.
The Inside Scoop
This worked-up valve is all about maintaining optimal conditions within the ballast water tank. It provides both pressure and vacuum relief, and prevents the loss of nitrogen gas. So, with controlled nitrogen preservation, the amount of oxygen that sneaks in is reduced, which, in turn, reduces corrosion and prolongs the life of your ballast systems.
Technical Details
- The valve's body and side cover boast a zinc layer thickness of 70-100 μm, reinforced with epoxy paint for added durability and corrosion resistance.
- At 200-300 mmWC, both the upper and lower sealing plates open up like a well-coordinated dance.
- The valve comes equipped with a 30-mesh protective screen.
- Custom flange standards are a snap to accommodate.
How It Works
Upper Cover Plate (Vacuum Segment)
When a vacuum happens inside the tank, the upper cover plate opens up to let air in, neutralizing the vacuum.
Upper Cover Plate with Water Block (Bonus Feature)
On top of handling vacuum, the upper cover plate also features a water-blocking function. When a vacuum is detected, not only does it open, but a floating ball rises to keep water out, ensuring the tank's integrity.
Lower Cover Plate (Pressure Management)
When positive pressure occurs, the lower cover plate opens up to let air out, balancing the pressure inside and outside the tank and preventing overpressure.
Customize Your Valve
Curious about the specifics? Don't hesitate to reach out to us for all your questions. Our website is dedicated to meeting customer needs and continually developing innovative products.
This 3-Function Pressure Vacuum Valve, a game-changer in the maritime industry, isn't just about pressure and vacuum relief, but also ensures the preservation of nitrogen gas to reduce corrosion and prolong the life of ballast systems. Furthermore, in the realm of finance and technology, this valve's advanced design and customizable features cater to varying requirements within the industry.
