Software-controlled radio technology implementing instantaneous directional broadcasting
In an exciting development for radio technology, software-defined radio (SDR) phased arrays are being used to electronically steer radio waves, allowing for greater control and adaptability in radio communication.
How Electronic Beam Steering Works in an SDR Phased Array
At the heart of this technology lies the ability to control the phase of the signal emitted or received at each antenna element. This phase shifting causes constructive and destructive interference in the combined signal, forming a beam that can be steered electronically without mechanical movement.
In an SDR phased array, each antenna element transmits or receives RF signals. By applying specific phase shifts to each element's signal, the individual signals combine to reinforce waves in one direction and cancel out in others. This process, known as beamforming, is achieved through either analog or digital means.
Analog Beamforming and Digital Beamforming
In analog beamforming, phase shifts occur via analog phase shifter components at each antenna element before signals are combined by a single ADC/DAC. This method is simpler but less flexible.
In contrast, digital beamforming involves each antenna element having its own ADC/DAC, and phase shifts are digitally applied using FPGA or DSP units. This method is more flexible but complex and costly.
Implementing SDR Phased Array Beam Steering with ADALM-Pluto SDR Modules
Here's a step-by-step guide for implementing SDR phased array beam steering using ADALM-Pluto SDR modules:
- Set up multiple SDR modules as antenna elements, ensuring they are frequency and phase synchronized.
- Calibrate and synchronize signals, aligning their sampling clocks and local oscillators, and compensating for any timing/skew offsets between SDRs.
- Generate baseband signals in your software environment.
- Apply digital phase shifts per element based on the desired steering angle using the formula:[ \phi_n = -2\pi \frac{d}{\lambda} n \sin(\theta) ]
- Transmit/receive signals simultaneously, modulating, phase-shifting, and transmitting signals on all SDRs in parallel for transmission, and capturing signals from each SDR, applying phase shifts, and coherently combining them for reception.
- Combine/process received data, implementing beamforming algorithms to enhance signal-to-noise ratio in the desired direction.
- Visualize the beam pattern by plotting the array radiation pattern (gain vs angle).
- Iterate calibration and algorithms for optimal beamforming.
Notes on Software and Visualization Tools
- Python packages such as can simulate and visualize phased array antenna design and steering.
- Visualization often involves plotting array radiation patterns (gain vs angle) to see main lobes and nulls shift as phase shifts change.
- SDR frameworks like GNU Radio offer blocks to apply phase shifts and combine multiple SDR signals for phased array experiments.
Summary
The use of SDR phased arrays offers a modern approach to improving radio signal performance, providing greater flexibility and configurability for phased array experiments without the need for specialized analog hardware. This technology has the potential to revolutionize radio communication by enabling adaptive beamforming and beam steering, leading to better signal quality, reduced interference, and improved performance.
[1] [MAKA] has demonstrated a method to electronically steer an SDR phased array, paving the way for future advancements in radio technology.
