Guide for Crafting Signal-Pure Connectors and Cables
In the realm of high-speed electronic systems, maintaining signal integrity is paramount. A key aspect of this is ensuring uniform impedance and minimizing electromagnetic interference (EMI) in cable and connector designs. Here are some best practices to achieve this goal.
Every signal transmitted through a wire requires a return path, either power or ground. This principle also applies to cables and connectors, where each wire should have access to a nearby reference conductor. A well-designed connector should ensure the return path is accessible for signals.
To achieve uniform impedance, it is essential to maintain consistent geometry and materials. Precise trace widths, spacing, and layer stack-ups, calculated based on transmission line impedance models, should be used. PCB and cable materials with stable dielectric properties and low tolerance variations, such as Rogers or Teflon-based materials, are ideal for this purpose.
Symmetrical routing of differential pairs is another crucial practice. Differential pairs should be routed with constant spacing and width to maintain the specified differential impedance. Asymmetrical spacing or placing components/vias between differential pairs should be avoided, as these create impedance discontinuities and degrade signal integrity.
Avoiding impedance discontinuities at transitions is equally important. Careful design is required when transitioning from PCB traces to cables/connectors to minimize reflections. Proper connectors rated for the application, matched to wire gauges and pitch, should be employed. Strain relief and environmental protection, such as molding or potting, should also be used to prevent mechanical stress and degradation affecting electrical contact quality.
Maintaining spacing is vital to reduce crosstalk and EMI. The minimum spacing between adjacent signal traces should be at least three times the trace width (3W), while differential pairs should be separated by at least 5W or more for clock signals. Components and vias should be kept out of the immediate differential pair region to avoid impedance changes.
Termination techniques can control reflections and ringing. Parallel or serial terminations that match the characteristic impedance of the transmission line should be implemented.
Minimizing trace length and vias is another key approach. Signal traces should be kept as short and straight as possible, and vias, especially for differential pairs, should be limited. Any required vias should be placed symmetrically to maintain impedance consistency.
Shielding and proper grounding are also important. Cables and connectors should be shielded as needed to reduce EMI susceptibility. Proper ground planes and return paths should be maintained, especially in mixed-signal or high-frequency designs, to control noise coupling.
Verification and measurement are crucial steps in the process. Time-domain reflectometers (TDRs), network analyzers, and in-circuit simulation tools should be used to validate impedance uniformity and identify potential EMI sources before and after manufacturing.
Collaboration with manufacturers is also vital. Working closely with PCB fabricators and connector vendors ensures that manufacturing processes can achieve tight impedance tolerances and consistent electrical performance. Controlled impedance testing is critical for high-speed interfaces, including USB and other protocols.
In high-speed designs, the most important thing is to have uniform impedance throughout the connector. In a cable assembly, the reference plane is replaced by a reference conductor. When the connector and cable have uniform impedance, signal integrity is maintained, and crosstalk is minimized. The reference wire should be grounded to avoid EMI.
Keven Coates, the Senior Electrical Engineer at Fluidity Technologies, emphasizes the importance of signal integrity in electronic systems. With 28 years of industry experience, he is currently working on the development of flying vehicles. The Fluidity Technologies design and assembly team is available to assist with questions on employing cables and connectors in designs to enhance signal integrity.
