Differences Between SAR and Delta-Sigma Analog-to-Digital Converters (ADCs)
In the realm of electronic product design, the choice of an analog-to-digital converter (ADC) plays a crucial role in achieving accurate and reliable data conversion. This article delves into the key differences between two popular ADC types: Successive Approximation Register (SAR) and Delta-Sigma (ΔΣ) converters.
Successive Approximation Register (SAR) ADCs
SAR ADCs offer a balance between moderate to high resolution, relatively fast sampling rates, and efficient power consumption. They are particularly suitable for general-purpose applications that require a balance between speed and resolution.
Resolution, an essential ADC specification, represents the number of possible output bits per conversion and the smallest analog increment that can be represented. SAR ADCs achieve resolution through a binary search algorithm, typically offering 12 to 18 bits, making them ideal for general-purpose applications.
Sampling speed is another critical factor, and SAR ADCs can handle faster sampling rates suitable for real-time and fast-changing signals. The conversion time for a SAR ADC is directly proportional to the number of SAR bits and the clock period.
However, SAR ADCs have limited noise reduction capabilities compared to ΔΣ ADCs, relying mainly on hardware quality for noise shaping.
Delta-Sigma (ΔΣ) ADCs
Delta-Sigma ADCs excel in achieving very high resolution and superior noise reduction through oversampling and noise shaping. They are ideal for precision measurements like audio, vibration, strain, and pressure sensing.
Delta-Sigma ADCs offer resolutions that can exceed 24 bits, making them the most resolution-efficient ADCs available. Their sampling rates are generally lower compared to SAR ADCs due to the oversampling and digital filtering processes involved.
In terms of noise reduction, Delta-Sigma ADCs use oversampling and noise shaping to push quantization noise out of the band of interest, followed by digital filtering to remove out-of-band noise. This results in superior noise reduction compared to SAR ADCs.
However, Delta-Sigma ADCs require more complex digital filtering and processing, and their free-running sampling (no trigger needed) makes them beneficial for continuous signal analysis like vibration and audio.
Comparing SAR and ΔΣ ADCs
| Feature | SAR ADC | Delta-Sigma ADC | |--------------------|--------------------------------------|--------------------------------------| | Resolution | Moderate to high (typically 12 to 18 bits) | Very high (can exceed 24 bits) | | Sampling Rate | Faster sampling rates | Slower effective sampling rate | | Noise Reduction| Limited noise shaping | Superior noise reduction | | Additional Points | Efficient for general industrial and consumer electronics | Requires more complex digital filtering and processing |
In summary, SAR ADCs are preferred when relatively high sampling speed with good resolution and moderate noise performance is required. On the other hand, Delta-Sigma ADCs are chosen for applications prioritizing maximum resolution and noise suppression at the cost of lower effective sampling rates.
This aligns with industry usage where SAR ADCs appear in multifunction data acquisition devices, while Delta-Sigma ADCs are favored for audio, strain gauge, and precision sensor measurements.
For instance, a 12-bit SAR ADC with a 5-V DAC reference can resolve an analog value as low as 1.22 mV.
Understanding the differences between SAR and Delta-Sigma ADCs is essential for making informed decisions when choosing the right ADC for your electronic product design needs.
