In the quest for a USB hub that can seamlessly blend into a Decora opening, a custom solution was devised. This article will detail the steps taken to create a USB hub that fits the standard size of a Decora device, and how this solution can be replicated by others.
Adapting USB Hub Modules to Decora Standards
The Decora device opening, typically measuring 2.62" x 1.3", poses a challenge when it comes to finding off-the-shelf USB hubs. However, DIY or semi-custom solutions exist, such as adapting USB hub circuit boards like the CoolGear CG-3510S4-Board to fit this space.
This process takes advantage of mounting holes and available technical drawings to ensure a snug fit within the Decora form factor. For instance, a simple flat rectangular plate with two holes was used to mount the USB hub in the Decora opening.
Cost Breakdown of the Custom USB Hub Solution
The total cost for this project, including the USB hub, mounting blocks, custom panel, hardware, and shipping, was approximately $75. The black anodized aluminum panel of 2 mm thickness, used for the custom panel, cost just under $30. It's important to note that the price per panel decreases with quantity when using Front Panel Express' services.
A Practical Solution for Conference Rooms and Home Theatres
This custom USB hub solution can be a valuable addition to conference rooms and home theatres, providing an easy and unobtrusive way to connect peripherals. Commercial USB extension or hub products designed with a Decora-compatible faceplate, such as Blustream’s UEX3H-WP-US and certain 4K HDMI/USB-C extenders, also offer practical integrated options.
For those in need of a purely USB hub (not extender) with Decora mounting, options might be limited, and a project like this custom solution may be required. However, USB extenders and combined AV/USB wall plate devices designed with Decora compatibility offer practical integrated options for these settings.
StudioHub Panels: A Decora-Compliant Option
StudioHub panels, which follow the Decora standard, provide a 19-inch rack panel (P/N SH-RACK4) for mounting up to four devices. These panels were installed during WETA's studio renovations, including a headphone amp, two-button panel for Live/Auto modes, and a three-button panel for EAS device control.
In conclusion, whether you're looking for a USB hub that mounts in a Decora standard opening or a ready-made USB extender or wall plate solution, consider adapting USB hub kits to Decora dimensions or exploring commercial options with Decora compatibility. This custom USB hub solution, along with other Decora-compliant products, can help streamline your conference room or home theatre setup.
